Structural Steel 2 x 2 x 1/4 Angle Line

2 x 2 x 1/4 Angle Line

The Structural Steel Angle Line is a hot-rolled, mild steel L-profile engineered for heavy-duty structural reinforcement and metal fabrication. This specific 2-inch by 2-inch equal-leg section features a 1/4-inch thickness, providing the high shear strength required for load-bearing frames and industrial supports. It meets standard structural grades for weldability and mechanical performance in demanding job-site environments.

Built for the Job

Contractors and metal workers specify this 1/4-inch profile when standard thin-gauge angles lack the necessary rigidity. The increased wall thickness allows for deeper weld penetration and higher torque resistance when using mechanical fasteners. It is a staple in civil engineering and heavy fabrication for creating stable junctions and rigid corners. Site crews frequently use this material for lintels, heavy-duty shelving brackets, and trailer chassis components. The mill finish surface accepts industrial primers readily after basic degreasing or scale removal.

• Fabricating heavy-duty gate frames and security grilles.

• Constructing structural supports for water tank stands.

• Creating mounting points for heavy machinery and equipment.

Product Highlights

High Load Capacity

The 6.35mm thickness ensures minimal deflection under vertical loads compared to lighter 3.0mm or 4.5mm alternatives.

Material Quality

• Standard mild steel grade for excellent weldability
• Consistent 90-degree internal radius for precise fitment

Technical Specifications

What’s Included

• 1 x Structural Steel Angle Line (Standard 6m Length or as specified)

On-Site & Workshop Notes

• Remove mill scale with a wire wheel or grinder before welding to ensure a clean, slag-free bead.

• Always apply a protective coating like red oxide primer or zinc-rich cold galvanizing spray to prevent oxidation.

• Use a high-speed chop saw with an abrasive disc or a metal-cutting circular saw for accurate 45-degree mitre cuts.

• Store this metal stock off the ground in a dry area to minimize surface rust during the construction phase.
