Bosch VDE TX 30 Screwdriver
The Bosch VDE Screwdriver TX 30 x 125mm provides certified protection for electrical professionals working on energized circuits up to 1000V AC. This specialized hand tool undergoes rigorous testing to meet the IEC 60900 international standard. It combines safety with the high-torque capabilities of the Torx drive system for demanding installation environments.
Built for the Job
Electrical contractors and facility managers utilize this insulated Torx driver for securing heavy-duty fasteners in distribution boards, control panels, and industrial switchgear. The TX 30 profile is frequently found in terminal block assemblies and mechanical electrical mounts where high clamping force is necessary. Unlike standard drivers, the protective insulation layer extends down the blade to prevent accidental short-circuiting against adjacent components or grounded enclosures during live-line maintenance. The S2 steel core ensures the tip maintains its geometry under heavy load, reducing the risk of cam-out which can damage sensitive electrical hardware.
-
Installation of industrial circuit breakers and contactors requiring TX 30 drive bits.
-
Maintenance of commercial HVAC control systems and heavy machinery wiring.
-
Assembly of solar inverter systems and high-voltage battery storage racks.
Product Highlights
- VDE Rated Safety
-
Each unit is individually tested in a water bath at 10,000V to guarantee safe operation at the rated 1,000V limit.
- Ergonomic Power Grip
-
- Dual-component soft-grip handle reduces hand fatigue during repetitive fastening tasks.
- Anti-roll handle geometry prevents the tool from sliding off inclined work surfaces or ladders.
Technical Specifications
| Specification | Detail |
|---|---|
| Drive Type | Torx (TX 30) |
| Blade Length | 125 mm |
| Voltage Rating | 1000V AC / 1500V DC |
| Blade Material | High-Grade S2 Steel |
| Compliance Standard | IEC 60900 |
What’s Included
-
1 x Bosch Professional TX 30 Insulated Screwdriver (125mm Blade)
On-Site & Workshop Notes
-
Inspect the red and yellow insulation before every use; if the inner layer is visible through nicks or cracks, decommission the tool immediately.
-
The handle end features a permanent size marking to allow for rapid selection when stored vertically in a technician’s tool pouch.
-
Store in a dry environment to prevent surface oxidation on the exposed TX tip, ensuring a clean fit into screw heads.
