Industrial Corrugated Coloured Iron Sheet 3m Tile Red

Corrugated Iron Sheet 3m

The Industrial Tile Red Sheet serves as a high-tensile roofing and cladding solution for residential and commercial structures. This 3-meter panel utilizes a cold-rolled process to achieve its corrugated profile, ensuring high load-bearing capacity and efficient moisture shedding. Contractors typically specify this material for its balance of weight and durability in diverse climatic conditions.

Built for the Job

This material is standard for primary roof coverings on timber or steel trusses. It also functions as a perimeter fencing solution for construction sites or as external wall cladding for warehouses and agricultural sheds. The 3-meter length minimizes joints on standard-sized outbuildings, reducing the risk of leaks at the laps. The corrugated geometry provides the necessary rigidity to span between purlins without sagging under environmental loads.

• Residential roof replacement and new builds on timber rafters.

• Side-wall cladding for industrial workshops and agricultural storage units.

• Temporary and permanent site hoarding or secure perimeter fencing applications.

Product Highlights

Multi-Layer Protection

The steel substrate undergoes a hot-dip galvanization process followed by a primer and an oven-cured polyester topcoat for longevity.

Standard Corrugation Profile

• 76mm pitch between crests for traditional aesthetics and water flow.
• 18mm depth provides structural stiffness across the 3-meter span.

Technical Specifications

What’s Included

• 1 x 3m Corrugated Iron Sheet, Tile Red

On-Site & Workshop Notes

• Always install with the side laps facing away from the prevailing wind direction to prevent moisture ingress. Use self-drilling screws with EPDM washers on the crests of the corrugations rather than the valleys to ensure a watertight seal. If cutting is necessary on-site, use cold-cutting shears instead of high-speed grinders to avoid burning the protective coating. Store these metal panels off the ground on a slight incline to prevent moisture entrapment between stacked units during storage.
