Powermax BSR 13A Socket
The Powermax BSR Twin Socket provides a high-density power distribution solution for modern commercial and residential infrastructure. This unit features two 13A British Type G outlets. It includes integrated USB-A and USB-C charging ports. The device operates on a standard 250V AC frequency. The black finish offers a professional appearance for enterprise environments. Each outlet utilizes a double-pole switch for complete circuit isolation. This design increases safety during maintenance procedures. Internal components feature high-conductivity copper alloys. These materials minimize electrical resistance. They also reduce thermal buildup under maximum load conditions. The integrated transformer converts AC input to a stable 5V DC output. It delivers a total of 3.1A across the charging ports. This configuration supports modern mobile hardware and legacy peripherals simultaneously. The BSR series utilizes a low-profile plate design to minimize the physical footprint on the wall surface.
Key Features
-
Dual Charging Interface
One USB-C port and one USB-A port provide versatile charging options for various mobile devices. -
Safety Shutter Mechanism
The internal shutters prevent accidental contact with live terminals when the socket is not in use. -
Terminal Configuration
- Large-bore terminals accept up to three 2.5mm² cables.
- Captive screws ensure efficient installation in high-volume projects.
- Angled entries allow for easier cable management within the back box.
-
Material Integrity
The faceplate consists of flame-retardant polycarbonate that resists impact and structural deformation. -
Circuit Protection
Additionally, the USB module incorporates short-circuit and overload protection to safeguard connected hardware.
Specifications
| Feature | Specification |
|---|---|
| Brand | Powermax |
| Series | BSR |
| Current Rating | 13A |
| Voltage | 250V AC, 50/60Hz |
| USB Output | 5V DC, 3.1A (Shared) |
| USB Ports | 1x USB-A, 1x USB-C |
| Switch Type | Double Pole |
| Mounting Depth | Minimum 35mm |
| Dimensions | 146mm x 86mm |
| Standards | BS 1363-2, BS EN 62368-1 |
| Carton Quantity | 50 pcs |
What’s in the Box
-
Powermax BSR Black Twin Socket with USB-A+C
-
M3.5 Fixing Screws
-
Installation Manual
Why Choose Powermax BSR 13A Socket
-
Consolidating four power points into a double-gang footprint saves wall space and reduces installation time.
-
Passive heat dissipation prevents the USB transformer from overheating during high-current charging cycles.
-
Silver-nickel alloy contacts ensure long-term switching reliability and minimal arcing in high-use environments.
-
The unit fits standard 35mm deep metal or plastic back boxes used in global electrical installations.
Kennedy Omondi (verified owner) –
Finally found a socket with a Type-C port that actually works for my newer iPhone cable. Very neat for the bedside and saves me from using those bulky adapters.
Mercy Chebet (verified owner) –
Bought these for my apartment renovation in Kilimani. They look very modern compared to the old-school white ones. The USB-A port is handy for my older tablet while the C port handles my phone perfectly. Only gave 4 stars because the delivery took an extra day, but the product itself is top notch and feels very solid.
Evans Juma (verified owner) –
Solid build quality from Powermax. I replaced the sockets in my home office with these SKTT models. It’s a real win because you don’t need those bulky ‘heads’ that usually block the second plug point. Both the Type A and C ports charge at a decent speed simultaneously without the faceplate getting too warm. If you have many gadgets, this is a mandatory upgrade for your house.
Silas Otieno (verified owner) –
It’s a good socket and the finish is quite nice for a modern interior. My only issue is the price is a bit on the higher side compared to the ones without USB, but I guess you pay for the convenience. Functional and looks like it will last.
