Powermax Universal Socket
The Powermax Single Socket Multi-Functional provides a versatile electrical interface for diverse plug standards in professional environments. This unit supports UK 3-pin, EU 2-pin, and US 2-pin configurations within a standard 86mm single-gang footprint. It handles a maximum current load of 13A at 250V AC. The internal architecture utilizes phosphor bronze contacts to maintain high conductivity over repeated insertion cycles. This specific SKU integrates a mechanical switch to isolate power at the point of use. The faceplate consists of high-impact polycarbonate to resist mechanical stress and thermal deformation.
Terminal connectivity relies on heavy-duty brass screw clamps. These terminals accommodate up to 3 x 2.5mm² or 2 x 4.0mm² conductors. The design prioritizes low contact resistance to minimize heat generation during peak load operations. Integrated safety shutters prevent accidental contact with live components. These shutters only retract when a standard plug earth pin or simultaneous neutral/live pins apply pressure. Additionally, the unit features a gloss finish that resists UV degradation and maintains structural integrity in varying humidity levels.
Key Features
-
Universal Interface Design
The aperture layout accommodates Type G, Type C, Type E, and Type A plug patterns without additional adapters. -
Material Specifications
- Flame retardant polycarbonate housing
- Urea resin internal base for high insulation resistance
- Phosphor bronze contact plates for spring tension retention
-
Safety Mechanisms
Internal protective shutters block access to live terminals when the socket remains unoccupied by a plug. -
Switching Performance
- Single pole mechanical toggle switch
- Silver alloy contact points to reduce arcing
- Rated for 15,000 switching operations under full load
Specifications
| Feature | Specification |
|---|---|
| Rated Current | 13 Amperes |
| Operating Voltage | 220V – 250V AC |
| Frequency | 50/60 Hz |
| Mounting Type | Flush or Surface Mount (86mm x 86mm) |
| Terminal Capacity | 3 x 2.5mm² or 2 x 4.0mm² |
| Contact Material | Phosphor Bronze / Silver Alloy |
| Standard Compliance | BS 1363 / IEC 60884 |
What’s in the Box
-
1 x Powermax Multi-Functional Single Socket
-
2 x M3.5 Fixing Screws
-
2 x Screw Head Covers
Why Choose Powermax Universal Socket
-
Eliminate the need for external travel adapters in commercial office spaces or hospitality projects.
-
Ensure long-term reliability with high-grade copper internal components that resist oxidation.
-
Maintain consistent aesthetics across electrical installations using standardized 86mm square dimensions.
-
Reduce installation time with accessible screw terminals and clear marking for live, neutral, and earth wires.
