Powermax Twin Socket
The Powermax Twin Socket 13a delivers a high-performance electrical interface for commercial and industrial power distribution systems. This dual-outlet unit integrates seamlessly into standard 2-gang electrical enclosures. It meets the rigorous requirements of BS 1363-2 standards. This ensures long-term reliability in high-traffic environments.
The housing uses high-grade polycarbonate or urea formaldehyde. These materials provide excellent insulation properties. They also offer high resistance to heat and fire. Internal components feature solid brass connectors. These ensure low resistance and minimal heat generation during peak current draw. Each socket outlet supports a full 13-amp load. The total capacity handles standard office equipment or industrial peripherals.
The switching mechanism provides a positive tactile response. It utilizes double-pole switching for enhanced safety. This disconnects both the live and neutral lines simultaneously. Such a feature is critical in sensitive electronic installations. Silver-alloy contact points prevent carbon buildup. This maintains low contact resistance over thousands of switching cycles.
Installation teams find the terminal arrangement efficient. The terminals are angled for easy screwdriver access. They accommodate up to three 2.5mm² cables or two 4.0mm² cables. This versatility supports various ring main configurations. The package includes M3.5 fixing screws for immediate deployment. The white finish provides a clean aesthetic for professional interiors. The surface resists UV yellowing over time.
The shutter system remains a core safety element. It requires the insertion of the earth pin to open the live and neutral apertures. This mechanical interlock prevents the insertion of foreign objects. Exterior dimensions follow the standard 146mm by 86mm footprint. This ensures compatibility with existing 2-gang backboxes. The module operates within a standard voltage range of 220V to 250V AC. It maintains performance across 50Hz and 60Hz frequencies.
Logistics managers appreciate the standardized packaging. Bulk orders ship in cartons of 50 pieces. This reduces handling time during site delivery. This Powermax hardware remains a staple for infrastructure projects requiring durable power points.
Key Features
-
Dual-Gang Configuration
Allows simultaneous connection of two high-current devices within a single wall-mounted footprint. -
Safety Shutters
Integrated mechanical shutters prevent accidental contact with energized internal components. -
Terminal Specifications
- Accepts up to 3 x 2.5mm² conductors
- Accepts up to 2 x 4.0mm² conductors
- Large-bore brass terminals for secure clamping
-
Switching Mechanism
Double-pole switches provide total isolation by breaking both live and neutral circuits.
Specifications
| Feature | Specification |
|---|---|
| Rated Current | 13A per outlet |
| Voltage Rating | 220-250V AC |
| Frequency | 50/60Hz |
| Configuration | 2-Gang (Twin) Switched |
| Standard Compliance | BS 1363-2 |
| Switch Type | Double Pole |
| Dimensions | 146mm x 86mm |
| Mounting Depth | 25mm (Minimum) |
| Carton Quantity | 50 Pieces |
What’s in the Box
-
Powermax Twin Socket Unit
-
Set of M3.5 Mounting Screws
-
Screw Cover Caps
Why Choose Powermax Twin Socket
-
High-capacity 13-amp outlets support demanding office hardware and network peripherals without overheating.
-
Double-pole switching ensures maximum electrical safety for technicians during maintenance and everyday use.
-
Standardized 2-gang dimensions ensure 100% compatibility with existing BS 4662 backboxes for rapid retrofitting.
-
Robust polycarbonate construction provides superior impact resistance and fire-retardant properties in commercial spaces.
