Powermax Twin Socket
The Powermax Black Matt Socket provides a high-current power interface for residential and commercial electrical systems. This hardware utilizes a twin-gang configuration to provide two independent 13A outlets from a single mounting point. It meets the rigorous requirements of BS 1363-2 for safety and performance. The internal architecture uses phosphor bronze contacts to ensure high elasticity and low contact resistance. Long-term reliability depends on these specific mechanical properties during repeated plug insertion cycles. The external plate features a non-reflective dark finish that resists fingerprints and reduces glare in high-lighting environments.
Key Features
-
Dual Gang Configuration
The unit provides two independent 13-ampere outlets within a standard double-gang footprint. -
Safety Shutter System
Internal mechanical shutters prevent access to live terminals unless the earth pin of a plug is fully engaged. -
Terminal Architecture
- Large brass terminal screws ensure secure cable retention.
- The design accommodates up to three 2.5mm² or two 4.0mm² conductors.
- Color-coded markings simplify identification during high-volume installation.
-
High-Grade Construction
The housing consists of flame-retardant polycarbonate that meets UL94 V-0 flammability standards.
Installation teams benefit from the clear terminal layout and shallow back-projection. This design allows more space for wiring inside a standard 35mm deep backbox. The double-pole switching mechanism enhances user safety by disconnecting both live and neutral lines simultaneously. This feature remains critical in modern electrical safety protocols for commercial buildings. The faceplate dimensions follow standard UK sizing for compatibility with existing galvanized steel or dry-lining boxes. Additionally, the unit operates within a temperature range of -5°C to +40°C while maintaining structural integrity under thermal stress.
The 13-ampere rating supports a wide variety of loads including server racks and office equipment. Procurement managers often select this model for large-scale office fit-outs because of its durability. The blackened aesthetic matches modern industrial design requirements. The switches provide a clear mechanical position for on/off status indication. Each carton contains 50 units to optimize logistics and reduce packaging waste on construction sites.
Specifications
| Feature | Specification |
|---|---|
| Current Rating | 13A per outlet |
| Voltage Rating | 250V AC, 50/60Hz |
| Compliance | BS 1363-2 |
| Mounting Type | Double Gang (2-Gang) |
| Finish | Matt Black |
| Material | Urea/Polycarbonate |
| Terminal Capacity | 3 x 2.5mm² or 2 x 4.0mm² |
| Switching | Double Pole |
What’s in the Box
-
Powermax Twin Switched Socket
-
2 x M3.5 Mounting Screws with matching finish
-
Installation Instructions
Why Choose Powermax Twin Socket
-
The dark-finish power outlet provides superior resistance to mechanical wear and surface scratching.
-
Phosphor bronze internal components maintain high clamping force over thousands of insertion cycles.
-
The double-pole switching design provides a higher level of electrical isolation than single-pole alternatives.
Kevin Omolo (verified owner) –
These black matt sockets look very classy compared to the standard white ones we usually see. I installed them in my living room against a grey feature wall and the finish is smooth, plus it doesn’t catch fingerprints easily. Good quality for the price.
Mary Wambui (verified owner) –
Installed two of these in the kitchen last week. They feel sturdy and the switches have a nice, firm click. Delivery to Westlands was also very prompt.
J.K. Mutua (verified owner) –
We used these for our office renovation in Upper Hill. The twin 13A capacity is perfect for workstations where you have a PC and a monitor running simultaneously. The black matt finish gives a very modern, professional look that doesn’t scratch as easily as the glossy versions. Definitely worth the upgrade if you want a premium feel in the office.
Brian Otieno (verified owner) –
Good value for money. The black finish is consistent across all five units I bought. My fundi had a bit of a challenge with the screw alignment on one of the back boxes, but once fitted they look top notch. Solid product for modern homes.
