Powermax Switch Pull
The Powermax Pull Cord Switch provides a robust solution for overhead electrical circuit management in commercial and residential infrastructures. This 10A rated device operates effectively at 250V AC frequencies. It integrates a mechanical toggle system actuated by a high-tensile nylon cord. The unit prioritizes safety by isolating the user from the primary electrical circuit. Engineers utilize this hardware in environments where wall-mounted switches are impractical or restricted by safety regulations. The internal components feature copper alloy terminals for optimal conductivity. A reinforced base plate ensures stable mounting on various ceiling surfaces. This overhead actuator meets standard compliance for low-voltage electrical accessories.
Key Features
-
Electrical Load Capacity
The internal mechanism supports a steady 10A current flow for lighting and low-power utility circuits. -
Contact Assembly
- Silver-nickel contact tips reduce contact resistance during operation.
- Spring-loaded toggle ensures rapid circuit breaking to prevent sustained arcing.
-
Enclosure Integrity
The high-impact polycarbonate shell provides thermal stability and resistance to chemical degradation over time. -
Mechanical Cord System
- 1.5-meter braided nylon pull-string facilitates extended reach for high ceilings.
- Reinforced cord attachment point prevents accidental detachment during high-force operation.
-
Installation Versatility
Large terminal apertures accommodate up to 2 x 1.5mm² cables for daisy-chain wiring configurations.
Specifications
| Feature | Specification |
|---|---|
| Model Number | SW-PMPLS |
| Current Rating | 10 Amperes |
| Voltage Rating | 250V AC |
| Switch Type | 1-Way Single Pole |
| Housing Material | Flame-Retardant Polycarbonate |
| Cord Material | Braided Nylon |
| Cord Length | 1.5 Meters |
| Mounting Type | Ceiling Surface Mount |
| Compliance | BS EN 60669-1 |
| Carton Quantity | 100 Units |
What’s in the Box
-
1 x Powermax SW-PMPLS Switch Pull Unit
-
1 x Pre-installed 1.5m Nylon Cord
-
1 x Surface Mounting Base
Why Choose Powermax Switch Pull
-
The overhead control unit offers superior mechanical life for heavy-duty commercial use.
-
This cord-operated actuator prevents direct contact with electrical terminals in damp environments.
-
It provides reliable manual ceiling trigger functionality for industrial lighting bays.
-
The mechanical isolation device features a robust housing that resists yellowing and UV exposure.
-
However, users must ensure the mounting surface supports the downward pull force of the mechanism.
-
Every component meets strict international safety standards for low-voltage switching devices.
Kevin Omondi (verified owner) –
Bought this for our master bathroom. The string feels strong, not like those cheap ones that snap after a month. It’s a 10A switch so it handles the lighting load without any issues. Delivery to Syokimau was fast. Very happy with the Powermax brand so far.
Beatrice Wanjiku (verified owner) –
Good quality pull switch. We installed it in the store room and it works smoothly. The white finish matches the ceiling well. Only gave 4 stars because the screws provided were a bit short for my specific mounting block, but the switch itself is solid.
Moses Kiprop (verified owner) –
Simple and effective. Using this for a small office project and it’s doing the job well. Standard 250V specs as advertised.
Fatuma Hassan (verified owner) –
It works fine and the price is fair for a 10A switch. However, the pull action is a bit loud—quite a heavy ‘click’. If you don’t mind the noise, it’s a very durable piece of kit for the price.
