Scanford Cooker Unit
The Scanford Cooker Unit 45A provides a centralized control point for high-power kitchen equipment. This assembly integrates a heavy-duty switch with a standard power outlet. It handles resistive and inductive loads typical of modern cooking ranges. Electrical engineers specify this hardware for its durability and thermal stability. The device manages 250V AC circuits in domestic and commercial environments.
Key Features
-
High Current Termination
The internal brass terminals support 45A continuous current for electric ovens. -
Safety and Compliance
- Double pole switching isolates both live and neutral lines.
- The unit complies with BS 4177 electrical safety standards.
- Neon indicators provide clear status for the cooker and socket.
-
Material Integrity
High-grade urea-formaldehyde construction ensures excellent arc resistance and thermal insulation.
Electrical contractors require robust termination points for high-wattage appliances. This module utilizes heavy-duty brass terminals to minimize resistance. Large terminal bores accommodate multiple 6mm or 10mm conductors easily. The faceplate consists of high-grade polycarbonate for impact resistance. Installers must use a minimum back box depth of 47mm for adequate cable management. The integrated 13A socket operates independently from the main 45A switch. This configuration allows users to power small appliances while the main oven remains isolated. Neon indicators use long-life discharge lamps for continuous visual monitoring. The switch mechanism provides positive tactile feedback during operation. Silver-nickel contact points reduce pitting and extend service life under inductive loads. Consequently, the hardware maintains low contact resistance over thousands of cycles. These units ship in cartons of 50 pieces for large-scale residential projects. It fits standard twin-gang mounting boxes for universal installation compatibility. The white gloss finish resists UV degradation and maintains professional appearance. Procurement managers value the balance of cost and technical performance in this series.
Specifications
| Feature | Specification |
|---|---|
| Current Rating | 45A (Main) / 13A (Socket) |
| Voltage | 250V AC |
| Switch Type | Double Pole (DP) |
| Terminal Capacity | 1 x 16mm² or 2 x 10mm² |
| Standard Compliance | BS 4177 |
| Mounting Box Depth | 47mm Minimum |
| Carton Quantity | 50 Pieces |
What’s in the Box
-
Scanford 45A Cooker Control Unit
-
M3.5 Fixing Screws
-
Screw Cap Covers
Why Choose Scanford Cooker Unit
-
The dual-switch design offers independent control for ovens and auxiliary kitchen tools.
-
Reinforced terminal blocks prevent overheating during peak electrical consumption periods.
-
Flush-fit dimensions ensure a clean integration with standard electrical infrastructure.
Brenda Chepngetich (verified owner) –
Fair price and does the job well. It feels a bit more plasticky compared to the expensive British brands, but for this price point, you can’t complain. It handles the load of my 4-plate cooker without any issues.
Otieno J. Omondi (verified owner) –
As a fundi, I prefer these Scanford CK-SC units because the terminals are wide enough for the heavy gauge 6mm cooker wires. The double pole safety gives the client peace of mind. The 45A rating is genuine—it doesn’t heat up even when the oven is running for long hours. Only wish the mounting screws provided were slightly longer for deeper boxes, but otherwise a solid buy for the price.
Faith Mutua (verified owner) –
Hii iko sawa kabisa. Very easy for my electrician to install and it looks neat on the kitchen tiles.
Kamau Njuguna (verified owner) –
This Scanford unit is actually quite sturdy. I like that it has the extra 13A socket because most cooker points in Nairobi apartments are usually alone. Now I can plug in the kettle without needing another wall outlet. Good stuff.
