Scanford SKTT-SC13 Socket
The Scanford Twin Switched Socket provides a dual-gang power interface for residential and commercial electrical circuits. This unit handles a 13A current load at a standard 250V AC frequency. It features double pole switching to ensure complete isolation of the live and neutral feeds. This configuration enhances safety during maintenance or appliance failure. The white urea formaldehyde construction offers high dielectric strength and heat resistance. Engineers specify this model for high-density deployments requiring reliable terminal connections. The rear housing provides ample space for 2.5mm or 4.0mm cable management. Each terminal accepts up to three 2.5mm conductors. This versatility supports ring main or radial circuit topologies.
Key Features
-
Double Pole Isolation
The switch mechanism disconnects both live and neutral lines simultaneously for enhanced electrical safety. -
Terminal Capacity
- Accommodates 3 x 2.5mm² conductors
- Accommodates 2 x 4.0mm² conductors
- Includes captive solid brass terminal screws
-
Safety Shutter System
A three-pin operated shutter design prevents unauthorized access to live parts when no plug is present.
The internal shutter mechanism prevents accidental contact with live components. This safety feature triggers only when the earth pin enters the socket. The copper alloy contacts ensure low resistance and minimal heat generation under full load. Installers benefit from the clear terminal markings on the rear molding. The captive screws remain in the terminal housing to prevent loss during mounting. This unit fits standard 25-millimeter back boxes for flush installations. For surface mounting, use a 35-millimeter pattress box to allow extra wiring space. The white finish resists UV degradation over long-term exposure. Each carton contains 50 units for bulk procurement requirements. The SKTT-SC13 undergoes rigorous testing to meet British Standards. This ensures durability in environments with frequent plug insertion cycles. The design accommodates standard UK three-pin plugs without overcrowding. Procurement managers select this model for large-scale infrastructure projects. It provides a balance of electrical integrity and cost-efficiency. The double-pole mechanism is essential for circuits where neutral-to-earth faults might occur. Total isolation prevents residual current leakage when the switch is off. The faceplate dimensions measure 146mm by 86mm. This standard sizing ensures compatibility with existing wall cutouts. The terminal screws feature a deep drive head to prevent stripping during high-torque tightening. High-grade urea materials provide natural antimicrobial properties. This makes the outlet suitable for healthcare or food preparation areas. The internal bridge links the two sockets securely. Each gang operates independently with its own rocker switch. The rocker action provides tactile feedback for clear status indication.
Specifications
| Feature | Specification |
|---|---|
| Current Rating | 13 Amps |
| Voltage Rating | 250V AC, 50Hz |
| Switch Type | Double Pole (DP) |
| Number of Gangs | 2 (Twin) |
| Terminal Capacity | 3 x 2.5mm² / 2 x 4.0mm² |
| Compliance | BS 1363-2 |
| Material | Urea Formaldehyde |
| Mounting Depth | 25mm Minimum |
| Fixing Centers | 120.6mm |
What’s in the Box
-
Scanford SKTT-SC13 Twin Socket
-
Set of M3.5 fixing screws
-
Screw cap covers
Why Choose Scanford SKTT-SC13
-
Double pole switching provides total circuit isolation for safer maintenance environments.
-
High-grade urea construction ensures fire retardancy and chemical resistance in heavy-use areas.
-
Captive terminal screws reduce installation time by preventing hardware loss during wiring.
-
Standardized 146mm dimensions allow for seamless replacement of existing dual-gang wall plates.
Josphat Mwangi (verified owner) –
I bought several of these for my house renovation in Syokimau. The double pole feature is quite reassuring for safety, especially for the kitchen area where we have heavy appliances. The switches have a solid click, not those flimsy ones that break after a month. Good value for money compared to the more expensive brands in the market.
Sarah Atieno (verified owner) –
Delivery to Thika was very fast. These Scanford sockets look very neat on the wall once fitted. Having a twin setup is much better than using extensions everywhere in the sitting room. Only giving 4 stars because the screws provided were a bit short for my deep wall boxes, so I had to use my old ones, but otherwise, the product is top notch.
Kevin Omondi (verified owner) –
Simple to install and works perfectly. The finish is clean and the DP switch gives peace of mind.
Fatuma Hassan (verified owner) –
We installed these in our small office in Westlands. They handle the computers and printers without any heating issues. Scanford is becoming a very reliable brand for our maintenance needs. Very sturdy build and the price is fair for a double socket.
Brian K. (verified owner) –
The socket itself is okay and the double pole switching is safe, but the plastic caps that cover the screws are a bit hard to pop in properly. Had to struggle a bit to get them flush. Still, for the price, it’s a decent buy for a 13A twin socket.
Mary Njeri (verified owner) –
Very happy with the purchase. These sockets feel heavy and well-made, not like the cheap light plastics you find in some shops downtown. Trustedbuilder delivered them the next day as promised. Highly recommend for anyone doing wiring or replacements.
