Powermax BSR Gold Twin Socket
The Powermax BSR Gold Socket provides a dual-outlet power interface for standard 13-amp electrical circuits. This unit features a distinct gold finish suitable for high-end commercial or residential installations. It complies with BS 1363 standards to ensure safety and reliability in power distribution. Each outlet operates independently with its own rocker switch. The internal contacts use high-grade copper alloys to minimize resistance and heat generation during high-load periods. The BSR series utilizes a rigid mounting plate to prevent warping during installation. The gold surface undergoes a specific finishing process to resist tarnishing and fingerprints. This ensures long-term aesthetic consistency in high-traffic environments.
Key Features
-
Standard Compliance
The unit adheres to BS 1363-2 specifications for 13A switched sockets. -
Terminal Configuration
- Accepts up to 3 x 2.5mm² conductors
- Captive screws prevent component loss during installation
-
Switching Mechanism
Double pole switching provides complete isolation of the connected load. -
Safety Integration
- Integrated child-resistant shutter system
- Fire-retardant urea formaldehyde faceplate construction
The BSR series incorporates a robust mechanical design to withstand frequent insertion cycles. The gold plating provides low contact resistance at the switch interface. This reduces the risk of arcing during operation. The internal shutter mechanism operates via the earth pin entry point. This safety feature remains mandatory for BS 1363 compliance. Each terminal accepts multiple cable gauges for ring main or radial circuit configurations. These units undergo rigorous testing for insulation resistance and dielectric strength. The double-pole switching mechanism provides a clean break for both active conductors. This isolation method is superior to single-pole alternatives in modern electrical installations. However, installers should verify the total load does not exceed the 13-amp rating per outlet. The twin configuration allows for efficient space utilization on modular wall plates. The BSR Gold series meets international requirements for low-voltage electrical accessories. Additionally, the unit fits standard UK-style mounting boxes with 60.3mm screw centers.
Specifications
| Feature | Specification |
|---|---|
| Current Rating | 13 Amps per outlet |
| Voltage Rating | 220 – 250V AC |
| Gang Count | 2 Gang (Twin) |
| Switch Type | Double Pole Rocker |
| Mounting Center | 120.6mm |
| Minimum Box Depth | 25mm (35mm recommended) |
| Standard | BS 1363-2 |
| Carton Quantity | 50 Pieces |
What’s in the Box
-
Powermax BSR Gold Twin Socket 13a
-
M3.5 Fixing Screws
-
Screw Cover Caps
Why Choose Powermax BSR Gold Twin Socket
-
High-conductivity phosphor bronze contacts ensure efficient power delivery and reduced heat build-up.
-
The double-pole switching architecture enhances user safety by disconnecting both live and neutral lines.
-
Standardized mounting dimensions allow for rapid integration into existing UK-style electrical infrastructures.
Kevin Mwangi (verified owner) –
The gold finish on these Powermax sockets is actually very elegant, not that cheap-looking yellow. I installed them in my main lounge and they look premium compared to the standard white ones. The switches have a firm click and the twin setup is perfect for my home theater setup. Delivery to Thika was faster than I expected.
Faith Chebet (verified owner) –
Good quality sockets for the price. The 13A rating handles my kitchen appliances without any heating issues. Only reason for 4 stars is I wish the screws provided were slightly longer for my specific wall boxes, but otherwise, the BSR Gold series is a solid choice for a modern house.
Juma Omondi (verified owner) –
Solid twin socket. The switching mechanism is smooth and the terminals are easy to wire. Good value for money.
