The Powermax BSR Gold Switch facilitates dual-point control for lighting circuits in residential and commercial environments. This 1-gang 2-way component integrates into standard mounting boxes. It handles a rated current of 10AX. The design accommodates inductive and fluorescent loads without premature contact wear. Engineers specify these units for stairwells, corridors, and large rooms where two control points improve efficiency. The internal mechanism utilizes high-conductivity copper alloy contacts. This choice minimizes electrical resistance. It reduces heat generation during peak operation. The gold-colored faceplate consists of impact-resistant polycarbonate. This material resists UV degradation and maintains structural integrity under varying temperatures. The unit includes clear terminal markings for rapid identification during installation.
Powermax BSR 1G2W
Electrical contractors benefit from the modular design of the BSR series hardware. The component fits standard 35mm deep back boxes. It allows sufficient room for cable management behind the plate. Captive terminal screws prevent loss during the wiring process. These screws accept up to 4x 1.5mm² or 2x 2.5mm² conductors. This flexibility supports various wiring topologies common in modern infrastructure. Each unit undergoes rigorous testing to ensure compliance with international safety standards. The 2-way functionality allows installers to configure the device as a 1-way interface if necessary. This versatility simplifies inventory management for large-scale projects. The rocker assembly provides a smooth action with a distinct click to confirm state changes.
Key Features
-
Load Compatibility
The unit handles 10AX inductive and fluorescent loads without contact welding or mechanical failure. -
Terminal Engineering
- Captive screws prevent component loss during high-volume site installations.
- Large terminal apertures accommodate multiple 2.5mm² cables for ring or radial circuits.
- Brass terminals ensure high conductivity and corrosion resistance over long deployment cycles.
-
Material Integrity
High-grade flame-retardant polycarbonate construction ensures the faceplate meets stringent fire safety requirements for commercial buildings.
Specifications
| Feature | Specification |
|---|---|
| Rated Current | 10AX (Inductive Load Rated) |
| Operating Voltage | 250V AC |
| Frequency | 50/60 Hz |
| Configuration | 1 Gang 2 Way |
| Material | Flame Retardant Polycarbonate |
| Mounting Type | Flush Mount (Standard 60.3mm centers) |
| Faceplate Dimensions | 86mm x 86mm |
| Compliance | BS EN 60669-1 |
| Carton Quantity | 100 Pieces |
What’s in the Box
-
Powermax BSR 1 Gang 2 Way Gold Switch
-
Mounting Screws (M3.5)
-
Screw Cap Covers
Why Choose Powermax BSR 1G2W
-
The gold-toned interface provides a professional appearance for upscale office spaces and commercial fit-outs.
-
Silver nickel contact points reduce arcing and extend the operational life of the internal mechanism.
-
The plate design ensures a flush fit against wall surfaces to minimize dust accumulation and gaps.
-
Bulk packaging in 100-unit cartons supports efficient procurement for large-scale electrical infrastructure projects.
