Scanford Elegance Bell
The Scanford Elegance Bell Switch facilitates reliable momentary contact for signaling systems. This component integrates into the wider Elegance series of modular electrical fittings. It supports a maximum current of 10A at 250V AC. The internal mechanism utilizes silver alloy contact points to minimize electrical arcing. This construction ensures longevity over thousands of operating cycles. The external plate consists of high-grade polycarbonate material. This thermoplastic offers flame retardancy and resistance to impact. It maintains structural integrity under varying environmental temperatures found in indoor installations.
Key Features
-
Momentary Contact Mechanism
The internal spring-loaded system ensures circuit completion only during physical depression of the button. -
Material Composition
- High-impact polycarbonate faceplate
- Flame-retardant internal housing
-
Terminal Configuration
Heavy-duty brass screw terminals support secure fastening for 1.5mm to 2.5mm copper wiring. -
Arc Suppression Technology
Silver alloy contact points reduce electrical wear during high-frequency operation. -
Mounting Compatibility
- Standard 86mm x 86mm dimensions
- Fits UK-style 1-gang mounting boxes
Specifications
| Feature | Specification |
|---|---|
| Brand | Scanford |
| Range | Elegance |
| Switch Type | Momentary (Bell Push) |
| Current Rating | 10A |
| Voltage | 250V AC |
| Material | Polycarbonate (PC) |
| Mounting Type | Flush Mount |
| Terminal Capacity | 2 x 2.5mm² |
| Compliance | IEC 60669-1 |
| Carton Quantity | 100 Pieces |
What’s in the Box
-
Scanford Elegance Bell Module
-
Mounting Screws (M3.5)
-
Screw Cover Caps
Why Choose Scanford Elegance Bell
-
Electrical contractors select this hardware for its standardized installation footprint and thermal stability.
-
The 10A rating provides a significant safety margin for standard low-voltage or mains signaling systems.
-
Silver-cadmium oxide contacts resist pitting and carbon buildup over time to maintain low contact resistance.
-
The unit fits standard 35mm deep back boxes with ample room for wire management and heat dissipation.
-
Mechanical components undergo rigorous stress testing to simulate decades of use in high-traffic environments. Consequently, the switch maintains performance in hospitality or commercial settings where usage frequency is high.
-
Logistics managers benefit from the bulk packaging configuration of 100 units per carton for large-scale deployments.
-
The unit adheres to IEC 60669-1 standards for switches intended for household and similar fixed electrical installations.
-
Testing protocols verify the insulation resistance exceeding 5 MΩ at 500V DC to ensure user safety.
