VIP Silver 2-Way Switch
The VIP Silver 2 Gang switch serves as a high-reliability electrical interface for modern lighting circuits. This specific model supports 10AX inductive loads. It facilitates two-way switching protocols across dual lighting zones. The unit utilizes a silver-coated polycarbonate faceplate. This material provides impact resistance and electrical insulation. Each rocker mechanism operates with a positive snap action. This ensures clean contact separation to prevent arcing. Engineers often specify this component for commercial environments requiring durable manual overrides. However, the depth of the backbox must be at least 25mm for optimal wire management. The internal architecture features high-grade copper alloy terminals. These terminals accommodate multiple cable cross-sections up to 2.5mm². The design adheres to BS EN 60669-1 standards for safety. This prevents yellowing over extended service lives.
Key Features
-
Dual-Gang Configuration
This hardware allows independent control of two separate lighting circuits from a single wall point. -
Two-Way Switching Capability
- Enables lighting control from two different physical locations.
- Supports standard 3-wire installation for multi-way circuits.
- Maintains circuit integrity in complex hallway or stairwell wiring.
-
10AX Inductive Rating
The switch manages fluorescent and LED loads without premature contact pitting or failure. -
Silver Finish Polycarbonate
- Resists chemical degradation from standard industrial cleaning agents.
- Provides a low-profile aesthetic suitable for modern office fit-outs.
- Includes UV-stabilized pigments to maintain color consistency.
Specifications
| Feature | Specification |
|---|---|
| Current Rating | 10AX |
| Voltage Rating | 250V AC, 50/60Hz |
| Terminal Capacity | 4 x 1.0mm², 3 x 1.5mm², 1 x 2.5mm² |
| Mounting Center | 60.3mm (Standard UK/BS) |
| Dimensions | 86mm x 86mm x 10mm |
| Compliance | BS EN 60669-1 |
| Carton Quantity | 40 Pieces |
What’s in the Box
-
1 x VIP Silver Dual-Gang 2-Way Switch Module
-
2 x M3.5 Fixing Screws
-
2 x Screw Cap Covers
Why Choose VIP Silver 2-Way Switch
-
The internal switchgear employs silver-nickel contacts for superior conductivity and thermal management during high-frequency operation.
-
Individual terminal markings facilitate rapid identification and reduce installation errors during large-scale site deployments.
-
A slimline profile ensures the unit fits flush against mounting surfaces for a professional finish in high-traffic corridors.
-
The 40-piece bulk packaging optimizes logistics for procurement managers overseeing multi-unit residential or commercial developments.
Evans Mwangi (verified owner) –
The silver finish looks very premium on my grey walls. Installed it in the master bedroom for the two-way switching and it’s working perfectly. Good quality for the price compared to what I saw in downtown shops.
Prudence Atieno (verified owner) –
Ordered these for a small office renovation in Westlands. Delivery was quick and the switches feel solid, not that light plastic stuff you find elsewhere. Only giving 4 stars because the packaging was a bit hard to open, but the product itself is top notch.
J. K. Thuo (verified owner) –
Solid 10AX switch. Does the job well and the silver color doesn’t fade or scratch easily during installation.
Brian Omondi (verified owner) –
It’s a decent 2-gang switch and the silver looks smart. However, the terminal space is a bit narrow if your fundi is looping many wires behind the plate. Once fitted it’s okay, but requires a bit of patience during the wiring stage.
