VIP Silver 1 Gang Switch
The VIP Silver 2 Way switch provides reliable lighting control for residential and commercial electrical circuits. This component integrates into the VIP Silver Series architectural range for consistent site-wide aesthetics. It supports 10AX inductive loads at 240V AC nominal voltage. The silver finish provides a professional appearance for modern infrastructure projects. Heavy-duty polycarbonate construction ensures the faceplate resists impact and UV degradation over time. This material maintains its structural integrity in high-traffic environments. The switch mechanism operates on a precision rocker-style pivot to deliver tactile feedback during every actuation.
Key Features
-
Silver Alloy Contacts
Internal contact points utilize silver alloy to minimize electrical arcing and extend the service life of the switch mechanism. -
Terminal Engineering
- Captive terminal screws prevent loss during high-volume installation phases.
- Large tunnel terminals accommodate up to two 2.5mm² solid core cables.
- Clear laser-etched markings identify Common, L1, and L2 connection points.
-
Load Compatibility
The 10AX rating handles the high inrush currents typical of modern LED drivers and fluorescent ballast systems.
The backplate design features standard 60.3mm mounting centers for compatibility with universal UK-style backboxes. Installation requires a minimum box depth of 25mm to allow for proper cable management and heat dissipation. The front plate clips securely to the internal grid to ensure a flush fit against wall surfaces. This unit complies with BS EN 60669-1 safety standards for general-purpose switches. Consequently, it meets the rigorous requirements of professional electrical inspectors and site managers. The silver coating undergoes a specialized application process to resist fingerprints and common chemical cleaning agents. Maintenance teams can sanitize the surface without risking finish degradation. The rocker mechanism is tested for 40,000 operations to guarantee long-term performance. Procurement managers benefit from the bulk carton packaging of 40 units per box. This logistical efficiency simplifies inventory tracking for large-scale commercial fit-outs.
Specifications
| Feature | Specification |
|---|---|
| Current Rating | 10AX |
| Voltage Rating | 250V AC |
| Switch Type | 1 Gang 2 Way |
| Material | Polycarbonate (PC) |
| Mounting Centers | 60.3mm |
| Minimum Box Depth | 25mm |
| Compliance | BS EN 60669-1 |
| Carton Quantity | 40 Pieces |
What’s in the Box
-
1 x VIP Silver 1 Gang 2 Way Switch Unit
-
2 x M3.5 Mounting Screws
-
Screw Cap Covers
Why Choose VIP Silver 1 Gang Switch
-
High inductive load handling prevents contact welding when controlling large LED arrays.
-
Two-way switching capability allows for multi-point control in corridors and stairwells.
-
Durable silver finish maintains a professional look without the maintenance requirements of metal plates.
