Powermax 1200mm Recessed Housing
The Powermax 4ft Fitting provides a robust structural framework for 1200mm lighting installations. This component utilizes cold-rolled carbon steel for the main body to maintain rigid alignment. It accommodates standard T8 or LED tube configurations within commercial electrical grids. The design prioritizes thermal dissipation to extend the operational lifespan of internal electronics. High-reflectivity internal surfaces maximize light output efficiency across the workspace. The unit integrates seamlessly into 600x1200mm modular ceiling grids. Heavy-duty spring clips secure the chassis against the ceiling substrate. This recessed architecture facilitates clean integration into suspended ceiling systems. The internal reflector optimizes the luminous flux distribution. It directs light downward to minimize spill into the ceiling void. Electrical safety remains a priority in the design. A dedicated grounding point connects directly to the metal chassis. This ensures compliance with regional building codes and safety standards.
Key Features
-
Structural Integrity
The chassis consists of high-grade cold-rolled steel to prevent warping during long-term operation. -
Electrical Configuration
- Pre-wired for 220V to 240V AC input
- Heat-resistant copper internal conductors
- Snap-lock terminal block for tool-less wire insertion
-
Mounting Mechanism
Spring-loaded clips provide a secure grip on T-bar rails for rapid deployment. -
Environmental Protection
- IP20 rated for indoor commercial environments
- White epoxy powder coating resists oxidation
- Polycarbonate end caps protect lamp holders from dust
Specifications
| Feature | Specification |
|---|---|
| Brand | Powermax |
| Model SKU | FT-PM4FT |
| Nominal Length | 1200mm / 4 Feet |
| Material | Cold Rolled Carbon Steel (CRCA) |
| Input Voltage | 220-240V AC 50/60Hz |
| Ingress Protection | IP20 |
| Finish | Epoxy Powder Coated White |
| Carton Quantity | 6 Pieces |
What’s in the Box
-
Powermax FT-PM4FT 4ft Fitting Chassis
-
Recessed Mounting Clip Set
-
Internal Wiring Harness
Why Choose Powermax 1200mm Housing
-
The 4-foot enclosure maintains strict adherence to industry dimensions for universal tube compatibility.
-
Maintenance personnel access internal components easily by removing the front cover for ballast inspection.
-
The unit operates efficiently within a temperature range of 0 to 50 degrees Celsius.
-
Low chassis weight reduces the mechanical load on ceiling suspension wires in large fit-outs.
-
Every unit passes a high-voltage leakage test at the factory to ensure operational reliability.
