Powermax Titanium Switch
The Powermax Titanium 2 Gang provides high-performance electrical switching for commercial and residential infrastructure. This unit features a dual-gang configuration within a single 86mm x 86mm plate. It facilitates two-way switching operations across two independent circuits. Users can control a single light source from multiple locations when paired with a secondary module. The titanium black finish provides a professional aesthetic for modern architectural environments. High-grade materials ensure long-term mechanical durability in high-traffic areas. This switch handles a standard 10AX inductive load. It operates efficiently at a rated voltage of 250V AC. The internal mechanism utilizes silver alloy contacts to reduce electrical arcing. This prevents carbon buildup during frequent operation cycles. The housing consists of flame-retardant polycarbonate for enhanced safety. It meets BS EN 60669-1 standards for electrical accessories. Large terminal capacities allow for the connection of multiple 2.5mm conductors. This simplifies the installation process for network engineers and electrical contractors. The product ships in cartons of 60 pieces for bulk procurement requirements.
Key Features
-
Two-Way Switching Logic
The internal circuitry allows for multi-point control of lighting loads across two separate gangs. -
Structural Integrity
- Reinforced polycarbonate mounting plate resists warping during installation.
- UV-stabilized titanium black finish maintains color consistency over time.
-
Contact Technology
Silver cadmium oxide contacts provide high conductivity and heat dissipation during peak loads. -
Terminal Design
- Angled terminal entries facilitate easier cable insertion in shallow backboxes.
- Captive screws prevent component loss during site assembly.
Specifications
| Feature | Specification |
|---|---|
| Brand | Powermax |
| Model Number | SW-PMT2G2WS |
| Gangs | 2 Gang |
| Ways | 2 Way |
| Current Rating | 10AX |
| Voltage | 250V AC |
| Frequency | 50/60Hz |
| Finish | Titanium Black |
| Material | Flame-retardant Polycarbonate |
| Dimensions | 86mm x 86mm |
| Fixing Centers | 60.3mm |
| Compliance | BS EN 60669-1 |
| Carton Quantity | 60 Pieces |
What’s in the Box
-
1 x Powermax Titanium Black 2 Gang 2 Way Switch
-
2 x M3.5 Mounting Screws
-
2 x Screw Cover Caps
Why Choose Powermax Titanium Switch
-
The industrial-grade silver alloy contacts ensure a mechanical life exceeding 40,000 operations.
-
Terminal capacities accommodate up to four 1.5mm cables or two 2.5mm cables for wiring flexibility.
-
Titanium black surfacing offers superior scratch resistance compared to standard painted finishes.
-
The low-profile design fits standard 25mm backboxes while providing ample space for conductor management.
Brian Ochieng (verified owner) –
The build is strong and the finish is premium. Only thing is it shows fingerprints quite easily because of the dark color, so you have to wipe it often if you want it looking sharp. Otherwise, the switching mechanism is very smooth.
Kelvin Mwangi (verified owner) –
I bought these for my duplex in Syokimau and the 2-way function works perfectly for the staircase lights. The Titanium Black finish is very classy and looks much more expensive than it actually is. It makes the usual white plastic switches look very outdated.
Faith Chepngetich (verified owner) –
The 2-gang setup is very convenient for our open-plan living area. My fundi had no issues with the installation. It fits perfectly into the standard boxes we already had. The Titanium Black looks very modern against our light grey walls.
Zubeida Omar (verified owner) –
Used these for a client’s office renovation in Westlands. The matte black color gives a very executive feel to the boardrooms. They have a solid click and the 2-gang plate is well-aligned. Good value for money.
Njeri Kamau (verified owner) –
Powermax never disappoints with these designs. I upgraded my whole house to this Titanium range and this 2-way switch is the best for the master bedroom entrance. It’s rare to find black switches that don’t feel like cheap plastic, but these ones are legit.
Joram Odhiambo (verified owner) –
Solid switch. Arrived on time in Kisumu and the build quality is top notch.
