Scanford 1.0mm Singles Wooden Cherry Switch

Scanford 1.0mm Switch

The Scanford 1.0mm Singles provides a robust electrical interface for low-voltage power distribution in premium environments. This component features a genuine Cherry wood finish designed to meet high-end architectural specifications. It maintains full compliance with international safety standards for both domestic and commercial applications. Engineers specify this series for projects requiring specific aesthetic finishes without sacrificing electrical integrity.

The internal mechanism utilizes high-quality copper alloy components for maximum efficiency. These parts ensure low contact resistance and high thermal conductivity during operation. The switch plate maintains an ultra-slim profile of only 1.0mm to minimize wall protrusion. This design creates a cleaner look in professional office environments or hospitality settings. The mounting frame uses reinforced steel to prevent plate deformation during the installation process.

The Cherry wood finish undergoes a specialized curing process to enhance durability. This treatment prevents the wood from cracking or fading under normal operating conditions. It also provides an additional layer of insulation against potential electrical leakage. Technicians secure the unit using standard M3.5 screws into existing back boxes. The rocker mechanism provides a tactile response upon actuation to confirm the change in state for the user.

The terminal configuration supports various cable gauges for flexible field wiring. It accommodates up to three 1.5mm² conductors or two 2.5mm² conductors easily. This flexibility allows for diverse wiring topologies including standard ring and radial circuits. The captive screw design prevents the loss of hardware during the mounting process. This unit operates effectively within a temperature range of -5°C to +40°C in controlled environments.

The internal springs use high-tensile steel to maintain consistent pressure over thousands of operations. This prevents the switch from becoming loose or failing prematurely under heavy use. The wooden exterior plate attaches securely to an internal polycarbonate chassis. This multi-layer construction provides both structural integrity and superior flame retardancy. The polycarbonate housing meets the UL94 V-0 standard for self-extinguishing materials.

Key Features

• Electrical Contact Integrity

  • Silver-nickel alloy contacts prevent arcing during load switching
  • Contact gap exceeds 3mm for safe isolation in the off position
  • Supports inductive lighting loads up to 10AX capacity

• Structural Composition

  • Natural Cherry wood veneer with UV-resistant protective coating
  • Reinforced steel mounting sub-frame for rigid wall attachment
  • Flame-retardant polycarbonate internal housing for safety

• Installation Specifications

  • Large-bore captive terminals simplify conductor insertion
  • Standard 60.3mm mounting centers for universal compatibility
  • Requires a minimum back box depth of 25mm for cable clearance

Specifications

What’s in the Box

• Scanford 1.0mm Single Switch Unit

• M3.5 Mounting Screws

• Installation Leaflet

Why Choose Scanford 1.0mm Switch

• The cherry-finished units provide a distinct aesthetic without compromising electrical safety standards.

• High-grade wood veneers undergo treatment to resist moisture and warping in varied climates.

• The slim 1.0mm profile ensures a flush fit against wall surfaces for a professional appearance.

• Brass terminals offer high torque resistance to ensure secure and permanent wiring connections.
