Scanford SCF01 LED Fixture
The Scanford 70W LED Fixture provides high-intensity illumination for industrial environments requiring robust ingress protection. This 1200mm luminaire utilizes an integrated SMD LED array to deliver consistent light output across its entire length. The mechanical design focuses on durability in harsh conditions where dust and moisture are prevalent. It operates on a standard AC voltage range and maintains high electrical efficiency through a dedicated constant-current driver. The enclosure uses high-grade polycarbonate to ensure resistance against physical impacts and environmental degradation.
Key Features
-
Ingress Protection Rating
The IP65-rated housing prevents the entry of fine particulates and protects internal components against low-pressure water jets. -
Thermal Management System
An internal aluminum PCB acts as a primary heat sink to dissipate thermal energy away from the LED diodes. -
Optical Performance
- High-transmittance frosted diffuser reduces glare without significant lumen loss.
- 120-degree beam angle provides wide coverage for warehouse aisles and workshops.
- Color Rendering Index (CRI) exceeding 80 ensures accurate color perception in technical tasks.
-
Electrical Specifications
- Integrated driver features a power factor greater than 0.9 for reduced reactive power.
- Input voltage compatibility ranges from 180V to 265V AC at 50/60Hz.
- Short-circuit and over-voltage protection circuits prevent catastrophic component failure.
Specifications
| Feature | Specification |
|---|---|
| Model | SCF01-4FT-70W |
| Power Consumption | 70 Watts |
| Length | 1200mm (4 Feet) |
| Luminous Flux | 8400 Lumens |
| Color Temperature | 6500K (Daylight) |
| IP Rating | IP65 |
| IK Rating | IK08 |
| Housing Material | Polycarbonate |
| Lifespan | L70 > 50,000 Hours |
What’s in the Box
-
1 x Scanford SCF01 4FT 70W LED Fixture
-
Stainless Steel Mounting Brackets
-
Installation Expansion Bolts
-
Sealing Glands
Why Choose Scanford SCF01
-
High luminous efficacy of 120 lm/W reduces total energy expenditure compared to traditional fluorescent systems.
-
The non-corrosive polycarbonate construction withstands humid and chemically active environments without structural degradation.
-
Instant-start capabilities eliminate the flickering and warm-up periods associated with legacy ballast-driven lighting units.
-
Stainless steel mounting hardware ensures secure installation in high-vibration industrial settings or heavy-traffic zones.
-
The integrated light source eliminates the need for tube replacements and minimizes long-term maintenance labor costs.
Evans Otieno (verified owner) –
I bought 10 of these for a renovation project in Industrial Area. The light output is very impressive for a 4ft unit, definitely more powerful than the standard 36W ones you find in most shops. My only small issue was the mounting clips are a bit stiff to snap on, but once it’s up, it’s very solid. Good value for money.
Mercy Mutua (verified owner) –
Hii taa iko sawa kabisa. The 70W is extremely bright, perfect for my workshop in Ruiru. No more dark corners and it handles the dust well.
Geoffrey Sang (verified owner) –
Solid fixture for the price. The dustproof seal is actually decent and doesn’t feel cheap. Delivery was fast.
