Scanford Cut Out
The Scanford Twin Cut Out provides a robust solution for electrical circuit protection and distribution in service intake applications. This unit facilitates the secure termination of incoming supply cables while offering integrated fuse protection for downstream circuits. Engineers utilize this dual-fuse assembly to manage two independent phases or provide loop-in loop-out connectivity in street lighting and commercial installations. The housing consists of high-impact, flame-retardant thermoplastic that resists UV degradation and mechanical stress. This material choice ensures a long service life in demanding environments where temperature fluctuations occur frequently.
Key Features
-
Terminal Architecture
The internal assembly features heavy-duty brass terminals with serrated bores to ensure maximum conductivity and cable retention. -
Housing Construction
- Glass-reinforced polyester or high-grade polycarbonate body.
- V0 flammability rating according to UL94 standards.
- Integrated moisture seals at cable entry points.
-
Safety Mechanisms
Internal safety shutters prevent accidental contact with live components during fuse replacement or maintenance cycles. -
Security Provisions
- Dedicated sealing wire holes for utility tamper evidence.
- Captive screw design to prevent hardware loss during field installation.
The mechanical design accommodates standard BS 1361 or BS 7654 fuse links, depending on the specific configuration required by the network operator. Technicians benefit from the spacious internal layout which allows for comfortable cable dressing of conductors up to 25mm². The twin-fuse configuration supports complex wiring topologies without requiring additional external junction boxes. This efficiency reduces the overall footprint of the electrical installation. The unit mounts easily to backboards or within lighting columns using standard fixing centers. Electrical continuity remains stable even under high vibration or thermal expansion cycles due to the spring-loaded contact pressure within the fuse carriers. This dual-pole protector serves as a primary isolation point for maintenance crews, ensuring circuit safety during downstream repairs.
Specifications
| Feature | Specification |
|---|---|
| Current Rating | 63A (Standard) / 100A (Max) |
| Voltage Rating | 240V / 415V AC |
| Terminal Capacity | Up to 25mm² |
| Fuse Compatibility | BS 1361 / BS 7654 |
| IP Rating | IP22 (Installed) |
| Material | UV Stabilized Thermoplastic |
| Mounting | Surface / Column Mount |
What’s in the Box
-
1 x Scanford Dual-Fuse Enclosure
-
2 x Removable Fuse Carriers
-
1 x Set of Cable Entry Grommets
Why Choose Scanford Cut Out
-
The high-torque brass terminals minimize voltage drop and prevent localized overheating at connection points.
-
Advanced thermoplastic polymers provide superior dielectric strength compared to standard PVC enclosures.
-
Pre-drilled mounting points and captive hardware significantly reduce installation time for large-scale infrastructure projects.
Kamau Njuguna (verified owner) –
Dealing with thick cables is usually a headache for most fundis but these terminals take 25mm wires without a struggle. I used this for a rental project in Ruaka and the build quality is very solid compared to the generic ones. The double pole gives that extra safety for the main switch. Definitely worth the price.
Beatrice Atieno (verified owner) –
Good price compared to what I found in some downtown shops. Arrived in Nairobi CBD the same day I ordered. The plastic casing feels tough and doesn’t crack even when you tighten the mounting screws firmly.
Evans Omari (verified owner) –
Proper 63A rating as advertised. Fits perfectly in the standard meter box and the connections are very secure.
Samuel G. (verified owner) –
Installed this for a small workshop. The twin cut out design is exactly what my electrician recommended for the 25mm incoming mains. It handles the load well without heating up.
Josphat Mwangi (verified owner) –
The unit itself is 100% fine and very heavy duty. However, the packaging was a bit squashed during delivery. Luckily the Scanford material is strong so no damage was done. Make sure you have a proper size screwdriver for those 25mm terminals.
Faith Mutua (verified owner) –
I always go for Scanford for my home electricals because of reliability. This double pole unit is very well made and Trustedbuilder delivered it on time. No complaints at all.
