Union 3 Lever Martin Handle Lock, Chrome, Mortice Door Set

Union Martin Handle Lock

The Union 3 Lever Lock provides a complete security and functional solution for internal timber doors in residential and light commercial projects. This Martin handle set combines a durable mortice lock body with ergonomic lever handles. It suits standard door thicknesses ranging from 35mm to 50mm, making it a versatile choice for site supervisors and locksmiths during first and second-fix installations.

Built for the Job

Contractors specify this hardware for its long-term reliability in high-traffic internal areas such as offices, bedrooms, or storage closets. The 3-lever mechanism offers a significant security upgrade over basic latch sets, ensuring the door remains secured against unauthorized entry without the complexity of a 5-lever insurance-rated system. The lever-on-backplate design simplifies the fitting process by covering existing holes and providing a clean finish on the door face.

• Internal office doors requiring medium security and privacy.

• Residential bedroom and study doors in multi-tenant builds.

• Refurbishment projects where standard mortice dimensions are required.

Product Highlights

Corrosion Resistance

The polished chrome finish provides a protective layer against moisture and frequent handling in humid environments.

Mechanical Integrity

• The lock case features a powder-coated steel finish to prevent internal rust and friction wear.
• Spring-loaded lever mechanism ensures the handle returns to a horizontal position even after years of use.
• Includes a reversible latch bolt that allows for quick installation on both left and right-handed door swings.

Technical Specifications

What’s Included

• 1 x Union Mortice Lock Body

• 2 x Martin Lever Handles (Pair)

• 2 x Steel Keys

• 1 x Strike Plate and Faceplate

• Installation Screws and 8mm Spindle

On-Site & Workshop Notes

• Ensure the mortice pocket is cut to the exact depth of the case to prevent the faceplate from sitting proud of the door edge.

• When reversing the latch, pull the bolt forward and rotate 180 degrees before snapping it back into the housing.

• Avoid using heavy oils or grease on the lever mechanism; a small amount of dry graphite powder is recommended for lubrication.

• Check the centers (usually 57mm) between the spindle hole and the keyhole before drilling to ensure perfect handle alignment.
