Junon 13A Socket
The Junon Champaigne Gold Socket provides a reliable 13A power interface for residential and commercial electrical infrastructures. This single-gang switched outlet adheres to BS 1363 standards for safety and compatibility. The unit utilizes a high-grade polycarbonate housing to resist impact and thermal stress. This specific model features a champaigne gold metallic finish applied through a durable coating process. It supports standard 250V AC circuits common in British-standard installations. Engineers often specify these components for projects requiring specific aesthetic finishes without compromising mechanical reliability. The internal architecture focuses on long-term conductivity and thermal management.
Key Features
-
Terminal Architecture
Large terminal apertures accommodate up to three 2.5mm² conductors for ring main configurations. -
Internal Contacts
- High-conductivity phosphor bronze construction for reduced heat.
- Silver alloy contact points minimize arcing during switch operation.
- Maintains consistent tension on plug pins over 15,000 cycles.
-
Safety Mechanisms
Integrated child-resistant shutters prevent accidental contact with live internal components. -
Material Properties
- Fire-retardant PC housing passes 850-degree Celsius glow-wire tests.
- UV-stabilized finish prevents discoloration from sunlight exposure.
Specifications
| Feature | Specification |
|---|---|
| Rated Amperage | 13A |
| Operating Voltage | 250V AC, 50/60Hz |
| Compliance | BS 1363-2 |
| Dimensions | 86mm x 86mm x 30mm |
| Mounting Center | 60.3mm |
| Switch Type | Single Pole Switched |
| IP Rating | IP20 |
What’s in the Box
-
1 x Junon 13A Switched Socket Outlet
-
2 x M3.5 Mounting Screws
-
2 x Screw Cap Covers
Why Choose Junon 13A Socket
-
The wiring device undergoes rigorous testing for mechanical endurance. It exceeds the standard requirements for switch mechanisms. The fire-retardant properties of the PC material ensure safety in high-load scenarios. Additionally, the finish resists UV degradation. Consequently, the hardware maintains its appearance over time. However, installers must ensure proper grounding during the flush-mount process. Silver alloy contact points minimize oxidation during operation. Therefore, the internal switching mechanism lasts longer than basic copper alternatives. The captive terminal screws prevent loss during the wiring process on-site. The standard footprint allows for simple replacement of existing 13A points. This component provides a balance of electrical safety and structural durability.
