Powermax CC-P5 5-Way Plastic Consumer Unit

Powermax CC-P5 Enclosure

The Powermax 5-Way Consumer Unit serves as a critical junction for electrical sub-circuit protection. This distribution board houses up to five individual modules on a standard DIN rail. The CC-P5 model uses high-grade, flame-retardant plastic for its main chassis. This material choice ensures electrical insulation and resistance to environmental moisture. It provides a safer alternative to metal enclosures in specific residential and light commercial settings. The unit includes a transparent smoke-colored cover. This lid allows technicians to verify the state of circuit breakers without opening the enclosure. It features a secure latching mechanism to prevent dust ingress and unauthorized access.

Inside the enclosure, the layout prioritizes thermal management and wire organization. The space behind the DIN rail allows for efficient cable routing. Manufacturers pre-install neutral and earth terminal bars to streamline the wiring process. These bars use high-conductivity brass to maintain low resistance across connections. The unit supports various cable entry sizes through its integrated knockouts. These knockouts reside on multiple faces of the box to accommodate different conduit orientations.

The surface-mount design simplifies installation on various wall types. It requires only basic mounting hardware to secure the backplate. The interior volume provides enough room for the minimum bending radius of standard copper conductors. This prevents mechanical stress on the wire insulation. The enclosure meets IP40 ingress protection standards. This rating protects against solid objects larger than 1mm while remaining suitable for indoor environments.

Maintenance personnel benefit from the clear labeling areas above each module. This allows for precise identification of circuits like lighting, power sockets, or dedicated appliance lines. The robust plastic hinges on the cover withstand repeated operation during testing and commissioning. This distribution board operates effectively at standard 230V or 400V AC ratings. It accommodates standard 18mm wide miniature circuit breakers. The internal busbar alignment ensures firm contact with modular devices. This reduces the risk of arcing at the connection points. The unit facilitates rapid upgrades or circuit additions within its five-module limit. Its compact dimensions make it suitable for installation in cupboards or small utility rooms.

Key Features

• Insulated Thermoplastic Housing
  The high-impact plastic construction resists corrosion and provides superior electrical insulation for internal components.

• Standardized Mounting System

  • Integrated 35mm DIN rail
  • Compatible with all 18mm modular MCBs and RCDs

• Transparent Inspection Cover
  The smoke-tinted flip-up lid enables immediate visual status checks of all installed circuit breakers.

• Pre-Configured Wiring Terminals

  • High-conductivity brass neutral bar
  • Dedicated earth bonding terminal block

Specifications

What’s in the Box

• Powermax CC-P5 5-Way Plastic Enclosure

• Neutral and Earth Terminal Bars

• Internal DIN Rail

Why Choose CC-P5

• Non-conductive chassis eliminates the risk of indirect contact shocks from the enclosure itself.

• Pre-formed cable knockouts reduce installation time and maintain a professional finish.

• Compact five-module capacity provides an efficient solution for small-scale electrical distribution tasks.
