Scanford 12W Surface Panel
The Scanford 12W Round Panel provides high-efficiency illumination for commercial and residential infrastructure. This surface-mounted light fixture utilizes edge-lit LED technology to deliver uniform light distribution across its circular surface. The unit operates on a standard 12-watt power draw while maintaining a high lumen-per-watt ratio. An integrated driver manages voltage fluctuations to ensure flicker-free operation. This luminaire eliminates the need for ceiling cutouts, making it suitable for solid concrete or wooden surfaces. The Cool Day (CD) color temperature creates a bright, neutral environment for high-productivity workspaces.
Key Features
-
Surface Mount Architecture
The chassis installs directly onto flat surfaces without requiring a recessed cavity or specialized mounting brackets. -
Advanced Optical Components
- The PMMA light guide plate prevents thermal yellowing over extended operating cycles.
- A high-diffusion opal cover scatters light at a 120-degree beam angle to minimize shadows.
-
Thermal Regulation System
A die-cast aluminum housing facilitates passive heat dissipation to protect the internal SMD LED chips. -
Electrical Stability Control
- The constant current IC driver supports a wide input voltage range of 85V to 265V AC.
- Built-in short circuit and over-voltage protection prevents damage during grid instability.
Specifications
| Feature | Specification |
|---|---|
| Power Consumption | 12 Watts |
| Color Temperature | 6500K (Cool Day) |
| Input Voltage | 85-265V AC, 50/60Hz |
| Luminous Flux | Approx. 960 Lumens |
| CRI | >80 Ra |
| Beam Angle | 120 Degrees |
| Housing Material | Die-cast Aluminum |
| Diffuser Material | Polycarbonate (Opal) |
| Lifespan | 30,000 Hours |
What’s in the Box
-
1 x Scanford 12W Circular Surface Panel
-
1 x Internal LED Driver
-
1 x Mounting Bracket and Screw Kit
Why Choose Scanford 12W Surface Panel
-
The 12-watt circular luminaire reduces maintenance overhead by providing a 30,000-hour operational life without bulb replacements.
-
High Color Rendering Index (CRI) values ensure accurate color representation for retail and detailed technical work environments.
-
Standardized packaging of 40 pieces per carton facilitates large-scale deployment for multi-floor facility upgrades.
-
The low-profile design maintains ceiling clearance while providing broad light coverage in areas with restricted vertical space.
-
Solid-state construction eliminates mercury and UV emissions, supporting green building compliance and workplace safety standards.
Kevin Mwangi (verified owner) –
I bought these for a project in Syokimau where the client had already finished the concrete slabs. Since we couldn’t do recessed lighting, these surface mount Scanford panels were the best alternative. The 12W output is quite strong for a small room. Build quality is decent for the price point and they sit flush against the ceiling without any ugly gaps.
Amina Hassan (verified owner) –
Good quality panels. We installed 8 of them in our small office space in Westlands and the light is very uniform. The Cool Daylight is perfect for working environments. Shipping was also quite fast.
Josphat Ochieng (verified owner) –
Safi sana. Bright and looks very neat on the ceiling. No flickering issues so far.
Beatrice Wanjiku (verified owner) –
Fair price for the Scanford brand. I have used their bulbs before and they tend to last longer than the generic ones in the market. These round panels have a nice slim profile for surface types, doesn’t look bulky at all.
Samuel Otieno (verified owner) –
The light output is great, exactly 12W as stated. My only small issue was that the mounting bracket feels a bit light, so you have to be careful when screwing it into a hard concrete ceiling so it doesn’t bend. Otherwise, the light itself is excellent.
Faith Mutua (verified owner) –
Very happy with the purchase. The cool daylight color is very clean and makes the room look modern. Used them for my kitchen area and the brightness is just right. Will be ordering more for the corridor.
