SF6324 Recessed Glass Downlight
The Unbranded 18+6W LED Panel provides a specialized lighting architecture for professional environments requiring both functional and aesthetic illumination. This SF6324 model combines an 18-watt primary light source with a 6-watt secondary pink perimeter. The central light delivers high-intensity cool daylight illumination at 6500K. A decorative glass ring produces a distinct pink glow around the outer edge of the fixture. This dual-circuit design allows for independent or simultaneous operation of the light sources through sequential switching. The fixture mounts flush within ceiling cutouts to maintain clean architectural lines in commercial or residential spaces. It utilizes a die-cast aluminum frame to facilitate effective thermal regulation during extended operation cycles.
Key Features
-
Dual-Circuit Lighting Modes
- Mode one activates the central 18W cool daylight LEDs for primary tasks.
- Mode two engages the 6W pink accent border for ambient lighting.
- Mode three illuminates both sections to achieve maximum lumen output.
-
Advanced Thermal Management
The integrated aluminum heat sink maintains low junction temperatures for the SMD 2835 LED chips to prevent thermal degradation. -
Optical Diffusion System
- High-transmittance glass panel ensures uniform light distribution across the 120-degree beam angle.
- The frosted diffuser surface eliminates hot spots and reduces glare in work environments.
-
Power Supply Stability
The external constant current driver protects the LED array from voltage fluctuations between 85V and 265V AC.
Specifications
| Feature | Specification |
|---|---|
| Model Number | SF6324 |
| Total Power Consumption | 24W (18W + 6W) |
| Primary Color Temp | 6500K (Cool Daylight) |
| Secondary Color | Pink |
| Input Voltage | 85-265V AC, 50/60Hz |
| Mounting Type | Recessed Ceiling |
| Beam Angle | 120 Degrees |
| Material | Die-cast Aluminum and Tempered Glass |
| LED Type | SMD 2835 |
| Operational Lifespan | 30,000 Hours |
What’s in the Box
-
1 x SF6324 Dual-Color LED Panel
-
1 x External LED Driver
-
2 x Spring Mounting Clips
Why Choose SF6324
-
The isolated driver design improves electrical safety by separating the high-voltage input from the low-voltage LED output.
-
Standard wall switches toggle between the three lighting modes without requiring specialized dimmers or controllers.
-
The 8mm tempered glass border provides structural rigidity and high light refraction properties for consistent accent colors.
-
High color rendering index ensures that the cool daylight LEDs offer accurate color representation in interior spaces.
