Powermax BSR Bell Switch
The Powermax BSR Bell Push functions as a momentary-action signaling interface for residential and commercial entry systems. This unit supports standard 250V AC electrical circuits with a maximum current rating of 10A. The external faceplate consists of high-impact, fire-retardant polycarbonate material. This construction prevents discoloration during long-term exposure to ambient light. The internal mechanism utilizes a high-tension spring for immediate return after compression. This hardware integrates into standard 1-gang electrical back boxes. It features a mounting screw pitch of 60.3mm for compatibility with existing infrastructure. The flush-mount design ensures a low-profile installation against the wall surface. Brass terminal blocks provide high conductivity and resist corrosion over the lifespan of the device. Each terminal accommodates multiple conductors for flexible wiring configurations.
Key Features
-
Momentary Contact Mechanism
The spring-loaded switch ensures the circuit remains closed only while the button is actively depressed. -
Terminal Capacity
- Accommodates up to four 1.5mm² conductors
- Features captive screws to prevent hardware loss during installation
- Utilizes brass inserts for high electrical conductivity
-
Material Durability
High-grade polycarbonate housing provides resistance to physical impact and thermal stress. -
Standardized Dimensions
- Fits standard 86mm x 86mm single gang back boxes
- Requires a minimum mounting depth of 25mm
Specifications
| Feature | Specification |
|---|---|
| Brand | Powermax |
| Series | BSR Switches and Sockets |
| Current Rating | 10A |
| Voltage Rating | 250V AC |
| Material | Polycarbonate (Fire Retardant) |
| Contact Material | Silver Nickel |
| Compliance | BS EN 60669-1 |
| Mounting Type | Flush Mount |
What’s in the Box
-
1 x Powermax BSR White Bell Push Switch
-
2 x M3.5 Mounting Screws
-
2 x Screw Cover Caps
Why Choose Powermax BSR Bell Switch
-
Silver alloy contact points minimize arcing and extend the operational life to 40,000 cycles.
-
The UV-stabilized white gloss finish maintains its appearance in environments with high natural light exposure.
-
Reinforced mounting apertures prevent the faceplate from cracking when applying torque to the fixing screws.
-
Non-ferrous metal components within the switch mechanism prevent magnetic interference in sensitive electronic environments.
-
Tactile feedback provides clear confirmation of switch activation for the end user. Consequently, this unit reduces the frequency of unnecessary repeat presses.
Kamau Njuguna (verified owner) –
Used these for a new site in Syokimau. The Powermax BSR is quite sturdy for the price. My electrician didn’t have any issues with the wiring terminals; they hold the cables firmly. It’s a clean white that matches the other sockets well and the click is very responsive.
Mercy Atieno (verified owner) –
Good bell switch. The action is smooth and it doesn’t get stuck like those very cheap ones from the local hardware. Arrived in Kisumu in good condition. Happy with the purchase.
Brian Kipkorir (verified owner) –
Simple, effective, and very easy to install. Does exactly what it’s supposed to do.
Fatuma Hassan (verified owner) –
I like the minimalist design of this switch. We put it at the main entrance of our clinic. It’s 10A so it’s more than enough for a standard doorbell setup. Very decent quality for this price point compared to other brands I’ve seen in the market.
Samuel Mwangi (verified owner) –
The switch is okay and looks smart on the wall. My only small issue is that the outer plastic casing feels a bit light, but for the price point, you can’t complain much. It functions perfectly and the 250V rating is standard for our local power. Good for budget-friendly renovations.
