Powermax TV Socket
The Powermax TV Switch establishes a high-performance termination point for coaxial RF distribution within structured cabling environments. This passive component facilitates the connection between terrestrial or cable signal sources and receiver equipment. It utilizes a standard 75-ohm impedance profile to prevent signal reflection and ghosting in high-frequency transmissions. The unit integrates into standard electrical mounting boxes used in commercial and residential infrastructure.
Engineers specify this hardware for its low insertion loss characteristics. The internal terminal block accepts standard RG6 or RG59 coaxial cables. A secure screw-clamp mechanism ensures a solid electrical contact with the center conductor. The outer dielectric shielding remains intact through the mounting process to minimize EMI/RFI ingress. This shielding is critical in high-density IT environments where multiple signal types coexist.
The faceplate consists of UV-stabilized polycarbonate material. This construction resists yellowing and mechanical impact over long service lives. The gloss finish provides a non-porous surface that simplifies maintenance in office settings. The design complies with BS 5733 standards for electrical accessories. It fits standard 35mm deep backboxes for optimal cable bend radius management.
Proper installation involves stripping the coaxial jacket to expose the dielectric and center copper core. Technicians must ensure the outer braid makes full contact with the grounding clamp. This configuration maintains the Faraday cage effect throughout the signal path. The front interface features a standard female IEC connector. This port accepts male RF flyleads from televisions or set-top boxes.
B2B procurement managers select these units for large-scale deployments in hospitality and multi-dwelling units. The standardized footprint allows for rapid replacement during facility upgrades. The internal architecture supports frequency ranges from 5 MHz up to 862 MHz for standard UHF/VHF signals. It also accommodates digital video broadcasting signals without introducing bit error rate spikes. This reliability reduces the need for frequent signal troubleshooting in complex MATV systems.
The component maintains a low profile against the wall surface. This reduces the risk of physical damage in high-traffic corridors or equipment rooms. The mounting screws remain hidden behind the terminal structure for a clean installation. Every unit undergoes factory testing for continuity and mechanical tolerances. This ensures consistent performance across bulk orders of 100 pieces per carton.
Key Features
-
Shielded Termination
The internal housing minimizes electromagnetic interference to maintain signal integrity across the distribution line. -
Physical Construction
- High-impact polycarbonate faceplate resists mechanical stress.
- Flush-mount design compatible with standard 86mm x 86mm backboxes.
-
Signal Optimization
The 75-ohm impedance matching prevents standing waves in high-frequency RF circuits.
Specifications
| Feature | Specification |
|---|---|
| Connector Type | Female Coaxial (IEC) |
| Impedance | 75 Ohm |
| Frequency Range | 5 – 862 MHz |
| Material | UV-Stabilized Polycarbonate |
| Mounting Standard | BS 5733 / 1-Gang |
| Carton Quantity | 100 pcs |
What’s in the Box
-
Powermax TV Socket Module
-
Mounting Screws
Why Choose Powermax TV Socket
-
Low insertion loss ensures maximum signal strength at the user endpoint.
-
Durable urea-formaldehyde or polycarbonate construction withstands industrial use cases.
-
Standardized dimensions facilitate integration with existing electrical gang boxes.
Otieno J. Omondi (verified owner) –
I bought several of these for a project in Syokimau. The build quality of the Powermax brand is always reliable and this coaxial socket is no different. It’s a simple female RF port but the plastic doesn’t feel cheap like the generic ones you find in some downtown shops. Very easy to wire up and the signal for the digital box is crisp.
Mary Wambui (verified owner) –
Good TV socket, it does the job well and fits perfectly on the standard wall box. Delivery to Thika was fast.
