Powermax Twin Socket
The Powermax Twin Socket Brushed facilitates reliable power distribution in professional and commercial electrical systems. This dual-gang component supports a 13A load across each outlet. It features a robust stainless steel construction with a protective lacquer coating. The unit complies with BS 1363-2 safety standards. This ensures compatibility with standard UK-style plug interfaces. Each terminal accepts multiple cable gauges for installation flexibility.
Key Features
-
Dual-Gang Configuration
The unit provides two independent 13A switched outlets on a single faceplate. -
Internal Safety Mechanisms
- Double-pole switching isolates both live and neutral conductors.
- Child-resistant shutter system prevents contact with live internals.
- High-conductivity copper alloy terminals minimize heat buildup.
-
Physical Durability
The 304-grade stainless steel faceplate resists physical impacts and corrosion. -
Installation Efficiency
- Large-bore terminals accommodate up to three 2.5mm cables.
- Captive terminal screws prevent hardware loss during mounting.
- Twin earth terminals support high-integrity earthing requirements.
-
Thermal Management
The internal architecture utilizes fire-retardant urea-molding to house the electrical contacts.
Specifications
| Feature | Specification |
|---|---|
| Current Rating | 13A |
| Voltage | 250V AC, 50Hz |
| Material | 304-Grade Stainless Steel |
| Finish | Brushed Steel (Lacquered) |
| Switch Type | Double Pole |
| Compliance | BS 1363-2 |
| Carton Quantity | 30 Pieces |
| Mounting Box Depth | Minimum 25mm, Recommended 35mm |
What’s in the Box
-
1 x Powermax 2-Gang 13A Switched Socket
-
2 x M3.5 Mounting Screws
-
1 x Installation Leaflet
Why Choose Powermax Twin Socket
-
The Powermax 13A dual-gang hardware provides a balance of electrical performance and structural longevity. Engineers prefer this series for its heat-dissipation properties during continuous load cycles. The low-profile design fits into 25mm back boxes for shallow wall installations. However, a 35mm depth is recommended for easier cable management. The double-pole switches enhance safety by fully disconnecting the circuit. This is critical in commercial environments where neutral-to-earth faults must be avoided. Additionally, the vertical grain finish hides surface oils. Therefore, the unit maintains a clean appearance in high-traffic areas. The mechanical components undergo testing for over 15,000 switching cycles. Consequently, procurement managers can rely on this hardware for long-term deployments. The inclusion of color-matched screws ensures a uniform look across the installation site. The unit operates effectively within a temperature range of -5°C to +40°C. This makes it suitable for diverse climate-controlled indoor environments. The lacquer coating is non-conductive, adding a layer of insulation to the exterior.
