PMax 32A Single Pole MCB 6kA

PMax 32A Breaker

The PMax 32A MCB provides essential overcurrent protection for electrical circuits in commercial and industrial environments. This single-pole miniature circuit breaker prevents damage from sustained overloads and high-current short circuits. It features a C-curve tripping characteristic designed for moderate inductive loads. The unit handles current spikes between five and ten times its rated capacity. This capability prevents nuisance tripping during the startup of servers and UPS systems. The 32-ampere rating supports branch circuits in data centers and telecommunications hubs.

The internal thermal-magnetic mechanism reacts to two distinct fault types. A bimetallic strip manages prolonged overloads by bending when excessive heat builds up. This movement triggers the latch to interrupt the flow of electricity. For instantaneous short circuits, an electromagnetic coil generates a force that trips the breaker immediately. This rapid response protects downstream hardware from catastrophic failure. The arc chute design effectively extinguishes internal sparks during disconnection. This reduces contact erosion over the lifespan of the device. Consequently, the hardware maintains low contact resistance throughout its operational cycle. The terminal clamps provide high pressure for secure wire retention. This prevents localized heating at connection points which could lead to fire hazards.

Installation utilizes a standard clip mechanism for 35mm DIN rails. This design ensures compatibility with most industrial enclosures and distribution boards. The 18mm width occupies exactly one module space in a standard panel. The toggle switch provides clear status indication for manual isolation and troubleshooting. Each unit consists of flame-retardant thermoplastic housing. This material withstands high temperatures without deformation. Procurement teams benefit from the standardized dimensions for high-density mounting. The 180-piece carton quantity supports large-scale infrastructure deployments.

Key Features

• Thermal-Magnetic Tripping
  Dual-layer protection mechanism responds to both slow-rising overloads and sudden short-circuit events.

• C-Curve Characteristic
  Optimized for inductive loads that require a higher trip threshold during initial power-up sequences.

• Standardized DIN Mounting

  • Fits 35mm top-hat rails
  • Tool-free installation clip
  • Single module 18mm width

Specifications

What’s in the Box

• 1 x PMax 32A Single Pole MCB

Why Choose PMax 32A Breaker

• High breaking capacity ensures the device interrupts high-energy faults safely without welding contact points.

• Robust thermoplastic housing maintains structural integrity under high-temperature conditions in crowded panels.

• Standardized 18mm module width allows for efficient space management in multi-circuit distribution boards.
