Powermax BRK-PMMCB10
The Powermax 10A MCB provides essential overcurrent protection for low-power electrical circuits in commercial and industrial environments. This miniature circuit breaker monitors current flow to prevent equipment damage from sustained overloads and sudden short circuits. It utilizes a C-curve tripping characteristic to manage moderate inductive loads without nuisance tripping. The unit mounts directly onto standard 35mm DIN rails for rapid integration into distribution boards. It maintains a compact 18mm width to optimize space within high-density consumer units.
Key Features
-
Thermal-Magnetic Trip Mechanism
The internal bi-metallic strip reacts to thermal overloads while an electromagnetic solenoid provides instantaneous protection against short-circuit faults. -
Advanced Arc Quenching
- Integrated arc chutes dissipate electrical arcs during high-current disconnection.
- Multi-plate cooling fins reduce contact wear during fault interruptions.
-
Contact Status Indication
The toggle switch features a mechanical flag indicator showing green for open contacts and red for closed circuits. -
Terminal Security
- Box-style terminals accommodate cable cross-sections up to 25mm².
- IP20-rated finger-safe housing prevents accidental contact with live components.
The 10-Ampere protective module consists of flame-retardant thermoplastic housing capable of withstanding high temperatures. This material ensures structural integrity during extreme fault conditions. The device supports a rated breaking capacity of 6,000 Amperes, allowing it to safely interrupt significant fault currents. It operates across a voltage range of 230V to 400V AC at a frequency of 50/60Hz. The mechanical service life exceeds 20,000 operations under normal load conditions. Silver-alloy contact points ensure low electrical resistance and minimize heat generation during continuous operation. This component complies with IEC 60898-1 international safety standards for household and similar electrical installations. Each unit undergoes rigorous factory testing to ensure trip accuracy within specified current tolerances. The side-clip mechanism allows for easy removal from the rail without disturbing adjacent breakers.
Specifications
| Feature | Specification |
|---|---|
| Rated Current | 10A |
| Tripping Curve | C-Curve |
| Breaking Capacity | 6kA |
| Number of Poles | 1P (Single Pole) |
| Rated Voltage | 230V / 400V AC |
| Mounting Type | 35mm DIN Rail |
| Terminal Capacity | Up to 25mm² |
| Compliance | IEC 60898-1 |
| Carton Quantity | 120 pcs |
What’s in the Box
-
1 x Powermax BRK-PMMCB10 10A MCB
Why Choose BRK-PMMCB10
-
The C-curve profile effectively manages inrush currents from small motors and lighting ballasts.
-
High breaking capacity ensures the safety of downstream IT equipment during severe electrical faults.
-
Standardized DIN rail mounting simplifies installation in modular power distribution systems.
-
The trip-free mechanism guarantees the circuit will open even if the toggle is held in the ON position.
