PMax 6A Circuit Breaker
The PMax MCB 6A Breaker provides essential overcurrent and short-circuit protection for low-voltage electrical circuits. This DIN-rail mounted component handles continuous loads up to 6 Amperes. It utilizes a thermal-magnetic tripping mechanism to safeguard downstream equipment. The device operates at a nominal voltage of 230/400V AC. This 1-pole module fits standard distribution boards. The 6kA breaking capacity prevents damage during high-energy faults.
The internal mechanism features a bi-metallic element for thermal protection. This element bends when temperature rises due to overload. The electromagnetic coil provides instantaneous protection against short circuits. This dual-action design ensures broad protection across various fault conditions. The C-curve tripping characteristic allows for moderate inductive inrush currents. This makes the unit suitable for lighting circuits and small motor loads. Terminal design accommodates solid or stranded copper conductors. The screw terminals provide high clamping pressure for low contact resistance. This reduces heat generation at the connection points.
The housing consists of flame-retardant thermoplastic. This material resists high temperatures and maintains structural integrity during faults. The front face includes a clear toggle switch for manual operation. It also serves as a visual indicator of the circuit status. Installation requires a standard 35mm DIN rail. The snap-on clip ensures a secure fit without specialized tools. Maintenance personnel can easily replace the unit if needed. The compact 18mm width saves space in crowded enclosures. Each carton contains 180 pieces for bulk procurement needs. This ensures availability for large-scale electrical infrastructure projects. Consequently, the unit provides a cost-effective solution for tiered electrical protection strategies.
The device meets international safety standards for miniature circuit breakers. It operates efficiently within a wide temperature range. Proper airflow around the module maintains its calibrated trip points. Designers should account for derating factors in high-ambient environments. This switchgear integrates into modern power distribution architectures. It provides a reliable disconnect point for maintenance and safety.
Key Features
-
Thermal-Magnetic Trip
The dual-function mechanism reacts to both long-term thermal overloads and instantaneous magnetic short-circuit events. -
Standardized Mounting
- Compatible with 35mm DIN rails
- Tool-free snap-on installation
- Compact single-module 18mm width
-
Terminal Security
Heavy-duty screw terminals support secure wire termination for both solid and flexible conductors.
Specifications
| Feature | Specification |
|---|---|
| Rated Current | 6A |
| Poles | 1-Pole (1P) |
| Breaking Capacity | 6kA |
| Tripping Curve | C-Curve |
| Rated Voltage | 230/400V AC |
| Frequency | 50/60Hz |
| Mounting Type | DIN Rail 35mm |
| Carton Quantity | 180 Pieces |
What’s in the Box
-
1 x PMax 6A 1-Pole Miniature Circuit Breaker
Why Choose PMax 6A MCB
-
High breaking capacity ensures the safety of downstream electrical assets during major fault conditions.
-
The C-curve characteristic provides versatile protection for a wide range of resistive and slightly inductive loads.
-
Robust thermoplastic construction guarantees long-term operational reliability in industrial environments.
